AS-Schneider Stabilized Connectors

ABOUT THIS PRODUCT

AS-Schneider Stabilized Connectors are close coupled to orifice meter / orifice fittings. The inlet connection (process connection), as standard, is 1/2 NPT male threaded. The Stabilized Connectors are always supplied in pairs. Depending on the application, a Stabilizer Shoe is supplied resp. recommended providing a very solid and efficient connection.

PRODUCT DETAILS

• Bore Size: 3/8″ (9.5 mm) – Roddable
• Stabilized connectors (always supplied as pair)

LONG TYPE

• Long Design
• Without isolation valve stem seal/packing
• Without isolation valve seat material

STC-LC00-1

• Carbon Steel A105 material
• Hex head bolts 7/16-20UNF x 1 1/4″ L, washers and PTFE seal rings

STC-LS00-1

• 1.4404 / 1.4401 / 316 / 316L stainless steel material
• Carbon steel hex head bolts 7/16-20 UNF x 1 1/4″ lg and washers in stainless steel seal ring in PTFE

SHORT TYPE

• Short Design
• Without isolation valve stem seal/packing
• Without isolation valve seat material

STC-SC00-1

• Carbon Steel A105 material
• Carbon Steel hex head bolts 7/16-20 UNF x 1 1/4″ lg and seal ring in PTFE

STC-SS00-1

• 1.4404 / 1.4401 / 316 / 316L Stainless Steel Material
• Stainless steel hex head bolts 7/16-20 UNF x 1 1/4″ L, washers and PTFE seal rings

INTEGRAL VALVE TYPE

• Integral Valve Design
• ETFE – 2,000psi (138 bar) Rated

STC-VCKE-1

• Carbon Steel
• O-ring FKM packing
• Hex head bolts 7/16-20 UNF x 1 1/4″ LG and washers in stainless steel seal ring PTFE

STC-VSPE-1

• 1.4404 / 1.4401 / 316 / 316L Stainless Steel Material
• O-Ring FEPM Stem Seal/Packing
• 1: Hex head bolts 7/16-20 UNF x 1 1/4″ LG, washers and PTFE seal rings
