ABOUT THIS PRODUCT
AS-Schneider S Type Block and Bleed Valve Manifolds are designed for mounting to Pressure Gauges, Pressure Transmitters, and Pressure Switches.
The standard vent connection is 1/4 NPT female. Pipe plugs are not installed as standard. S Type Block and Bleed Valves are offered in 1/4″ NPT and 1/2″ NPT in male or female inlet and outlet connections. Rated up to 10,000psi allows these block and bleeds to fit most application needs.
PRODUCT DETAILS
- Block and bleed manifolds
- 1/4″ Female NPT (National Pipe Thread) vent connection
- Male inlet
- Female outlet
- PTFE (Polytetrafluoroethylene) Bonnet
SAMFCA-N4N4-0001
- Carbon steel material
- 1/2″ NPT Inlet
- 1/2″ NPT Outlet
- Extended Body, Includes Vent Port Plug and Outlet Multiport
- Max pressure 6,092 psi at 60 deg C (140 deg F)
SAMFSA-N4N4-AH
- 1.4401 / 1.4404 / 316 / 316L stainless steel material
- 1/2″ NPT Male thread inlet type
- 1/2″ NPT Female male/female thread outlet size
- Vent ports plugged
- 10,000psi for PTFE packing
