ABB UFLO G5 Flow Computer

ABOUT THIS PRODUCT

The ABB μFlo G5 is the latest version of the most popular single-run gas flow computer in North America. The primary market for the μFlo G5 is single-run gas measurement, yet a powerful processor and expansion allows multiple-run gas and liquid measurement as well. Single run measurement with optional multi-run when adding ABB MODBUS 266 multivariable sensors. For basic gas or liquid measurement applications that do not require control, the μFlo G5 is your solution.

PRODUCT DETAILS

Time-tested and field-proven, the μFlo flow computer is known in the industry as extremely accurate and reliable. The latest version, G5, features a new operating system, persistent memory, and supports linear liquid measurement.

• Low cost, high reliability, backward compatible
• 9-30 VDC operation
• 300 MHz Processor and persistent memory so your data is never lost
• Integrated 10/100 Base-T Ethernet port
• Linux operating system
• Gas measurement utilizing the latest AGA3, AGA7, AGA 11 and API 21.1 standards
• Liquid linear measurement with implementation of API 11.1 for crude oil, API 11.2 for light hydrocarbons, and API 11.4 for water measurement and API 21.2 for data logging and events
• Optional expansion board available
• 1 additional user configurable RS232/RS485 communications port
• 1 Digital Output
• 1 Digital Input (up to 20 kHz)
• 2 Analog Inputs (4-20 mA or 1-5Vdc)

uFLO6213

• C/US, CSA Cert, Class I, Div 2, Grp CD, NI
• Enclosure Assy, 6213, G5
• Selectable RS232 or RS485 for uFLO6213
• MMI External, PCCU Serial
• Board, communications, I/O expansion board for uFLO6213, adds one software-selectable RS232/RS485 communication port, two AI’s, one DI/PI, and one DO.
• IMV G5, Carbon Steel, Accuracy .075%, flow is right to left/absolute pressure on high (Model # Cross Ref 4XXIYC), DP = 250, AP = 1500
• Mounting Kit, for 2 inch pipe mount or wall mount
• RTD Probe Assembly, 10 foot, stainless steel, braid (Standard Pick)
• Tag, uFLO G5, 6213 size Enclosure
• Flash, Standard App, G5 µFlo
• Config File, US, AGA3, uFLO G4/G5, Std Pick
• Flash, Boot 1, Secure With Keys
• FLASH, OS, LINUX 3.12.X
• Additional Software Apps, if more than 2 free Apps are required. User selectable.

uFLO6213Y

• NRTL/C certified to install in Class I, Div 2 area
• Enclosure assembly, 6213 G5
• MMI External, PCCU serial
• Selectable RS232 or RS485 for uFLO6213
• No additional I/O expansion board
• IMV G5, Carbon steel, accuracy .075%, flow is right to left/absolute pressure on high (Model #Cross Ref 4XXIYC), DP = 800, AP = 1500
• Mounting kit, for 2 inch pipe mount or wall mount
• RTD Probe assembly, 10 foot stainless steel, braid (Standard Pick)
• Tag, uFLO G5, 6213 size Enclosure
• Flash, Standard App, G5 µFlo
• Config file, US, AGA3, uFLO G4/G5, Std Pick
• Flash, Boot 1, Secure With Keys
• FLASH, OS, LINUX 3.12.X
• Software Apps, 2 Included, over 2 select APXX at additional cost
